Overview

Keeping your home comfortable and warm is a high priority, but it doesn't have to come at a high cost. Whether you heat by baseboard, panel radiators, hydro-air systems or radiant flooring, our advanced heating systems will provide many years of exceptional comfort and savings. A conventional boiler heats and circulates water at only one temperature; typically 170 to 180 degrees until the thermostat signals it to stop. A Buderus boiler, especially when paired with the Logamatic control, eliminates these room temperature swings by adjusting the boiler water temperature to the current conditions, saving fuel while keeping you warm and comfortable. Sections are assembled with beveled, surface profiled push nipples for long, trouble free watertight operation. Flueways are sealed gas tight with tongue and groove section design and elastic high temperature resistant sealing rope. This seal is fully pressed into the groove during assembly to allow positive pressure operation. A permanent dry door gasket ensures repeated positive sealing off of the full swing burner door, producing a proven gas tight seal. Buderus GL-180M silicone injected, gray cast iron has excellent corrosion resistance, exceptional casting characteristics, 40% greater flexibility and elasticity as well as highthermal conductivity. Buderus developed the special substances that are impregnated during the casting process to improve the mechanical properties of cast iron. The graphite precipitates into smaller, modified flakes which produce GL-180M cast iron with 40% greater elasticity and a high silicone barrier for corrosion protection. Gray cast iron obtains its superior material characteristics primarily from a high carbon (graphite) and silicone content.

Features

• 154,000 BTU input - 134,000 BTU heating capacity
• Designed to operate at any return water temperature
• Full swing burner door can be hinged on either side
• No refractory parts for reduced maintenance
• Boiler is fully serviced and cleaned from the front
• Cast iron breaching for long life
• Thermostream design increases efficiency and reliability
• High efficiency through full three pass boiler design
• Includes standard B-Kit consisting of: burner mounting bolt set, 1-1/2 inch x 1-1/2 inch x 1/4 inch supply manifold, 1-1/4 inch x 3/4 inch BMI bushing, 1 inch BMI plug, 3/4 inch BMI street 90 elbow, 3/4 inch quarter turn boiler drain, 30 PSI relief valve, and tridicator.
• Rear tappings and flue connection
• Baffles and clips for adjusting stack temperatures
• Front access plugs for flushing the boilers interior
• Three inch thick thermal insulation
