Peerless Boilers SCT-06-W Water Boiler less Burner
Item SKU - SCT-06-W by Peerless Boilers
EDP - 844570
Please Login for Pricing
Product Description
Features
- 490,000 BTU input - 409,000 BTU heating capacity - 85.4% Combustion Efficiency
- The boiler is shipped knocked down with block assembled - No Burner - No Low Water Cut Off - No Circulator
- Cast iron sections - Insulated powder coated steel jacket - Limit control with manual reset - Burner mounting plate with observation port
- Left hand side cleanout plate - Top flue outlet with locking damper - Tankless Opening with Cover Plate
- Aluminized steel flue collector - Target wall and Cerafelt base liner
Documentation
Specifications
These specifications are subject to change by the manufacturer, and are only approximate. For precise specifications, please call our inside sales department at 860-221-SALE (860-221-7253).
Fuel Type
Oil
Natural Gas
Type
Water
Heat Exchanger Material
Cast Iron
BTU Input
490000
BTU Output
409000
Domestic Hot Water
No
Vent Type
Atmospheric Vent
Building Type
Commercial
Length (inches)
28.75
Width (inches)
22.50
Height of Boiler (inches)
43.25
Vent Material
Galvanized
All Fuel
Supply
Female Iron Pipe 2
Return
Female Iron Pipe 1 1/4
Vent Size (inches)
9
Net BTU
356000
Approximate Weight (pounds)
910
