Peerless Boilers 1606145 ECT-06-WU Oil Water Boiler with Beckett CF-375 Burner less Circulator
Item SKU - 1606145 by Peerless Boilers
EDP - 770237
Please Login for Pricing
Product Description
Features
- If boiler is fired at 2.25 gallons per hour: 385,000 BTU input - 321,000 BTU heating capacity - 84.4% Combustion Efficiency
- If boiler is fired at 2.50 gallons per hour: 420,000 BTU input - 347,000 BTU heating capacity - 83.7% Combustion Efficiency
- The boiler is shipped knocked down and with all 3 nozzles, and has the 2.50 nozzle installed - Beckett CF-375 oil burner
- Cast iron sections - Deluxe Classic powder coated steel jacket - Boiler reset control with Hydrolevel 3250 Low Water Cut Off
- Full plate swing out burner door - Top flue outlet - Side cleanout - Draft regulator - Tankless Opening with Cover Plate - Less circulator
Documentation
Specifications
These specifications are subject to change by the manufacturer, and are only approximate. For precise specifications, please call our inside sales department at 860-221-SALE (860-221-7253).
Fuel Type
Oil
Type
Water
Heat Exchanger Material
Cast Iron
BTU Input
420000
BTU Output
347000
Domestic Hot Water
No
Vent Type
Atmospheric Vent
Building Type
Residential
Length (inches)
41.3125
Width (inches)
22.5
Height of Boiler (inches)
42
Vent Material
Galvanized
All Fuel
Supply
Male Iron Pipe 2
Return
Female Iron Pipe 1 1/4
Vent Size (inches)
9
Approximate Weight (pounds)
1030
