Features

• Tough heavy duty cast iron head with bucket hook has excellent flow characteristics, is tapped with a 3/4" FPT outlet and comes complete with a removable 3/4" GHT brass garden connector
• Large heavy duty handle has longer hand grip for comfortable operation. It can be held firmly in any position to regulate flow by means of a S.S. thumb bolt and has a locking ete allowing the hydrant to be pad-locked in the closed position
• Polished stainless steel operating rod reduces wear on the stem packing and provided maximum corrosion resistance
• Double O-ring sealing system provides a positive seal between the hydrant head and operating rod. The O-rings are easily replaced, a great advantage over yard hydrants that use stem packing which is very difficult to remove and clean out of the head casting
• One piece zinc plated pivot connector complete with a square head S.S. set screw allows for easy adjustment of the linkage
• double zinc plated draw straps provide excellent corrosion resistance; have smooth operation with very limited play in the linkage
• 1" Galvanized ASTM A53 Sch. 40 Standard Pipe (304 S.S. Sch. 40 Pipe is available)
• 3/8" Steel connecting rod & coupling
• Bronze and No Lead Bronze valve body offer superior flow rates, a self draining bleeder port (tapped 1/8 FPT) prevents riser pipe and valve head from freezing, available in a 3/4" FPT or 1" FPT
• One piece plunger buna-n-rubber molded over stainless steel insert with triple groove design ensures that there is no chance of the rubber detaching from the stainless core. The self-lubricating rubber prolongs the life of the plunger
• Max pressure - 125 PSI
• Max temperature - 120 degrees F (48 degrees C)
